Big enough for Video Village. Bright enough for daylight viewing. Lightweight and rugged for challenging locations.

The Cine 18 offers a perfect blend of screen size, brightness, color-accuracy, and portability, making it the most flexible High-Bright 4K Monitor for any production scenario. It’s big enough for Video Village, bright enough for daylight viewing, and its ultra-lightweight aluminum unibody construction is the result of years of real-world, on-set testing. This monitor is ideal for Video Village, ACs, DPs, DITs, or as a director’s monitor.

The Cine 18” 4K High-Bright monitor features 1100nits of brightness for easy daylight viewing, exceptional image quality, and up to 4K resolution on the monitor’s 18-inch creen. 10-bit color depth and 100% REC.709 color gamut ensure a color-accurate look at your production.

Cine 18 features four 12G SDI inputs and outputs as well as one HDMI 2.0 input. The Unibody Smart Chassis offers a VESA pattern for mounting and 2x 2-pin accessory power outputs. Hot-swappable dual inputs allow you to add on Gold Mount or V-Mount battery plate attachments.

Meet Our Smart PageOS Software

With the power of SmallHD PageOS software, build customized Page Profiles, and utilize all of the dependable SmallHD features such as personalized frame guides, Focus & Exposure Assist, high-resolution 3D LUT overlays, histogram, vectorscope, waveform, and more.

Features:

• 18.4" UHD 4K monitor
• 3840 x 2160 resolution
• 1100 cd/m² brightness
• 1300:1 contrast ratio
• Four 12G/6G/3G/HD-SDI inputs and four 12G/6G/3G/HD-SDI outputs
• One HDMI 2.0 input
• SD card slot for 3D LUTs
• One RJ45 Ethernet port
• One RJ45 GPI port
• 1/4"-20 mounting threads on top and sides

Power Options:

• One 4-pin XLR 12 to 24V, 12A input
• Two 2-pin LEMO 12V, 2A outputs
• One USB-A 5V, 2.4A output
• One USB-A 5V, 1.5A output
• One USB-C 5V, 1.5A output
• Separately available V-mount or Gold mount battery plates
• XLR and battery options are hot-swappable

Compatible With:

• Cheese Plate for SmallHD 4K Monitors
• Dual V-Mount Battery Bracket (14v/26v) for SmallHD 4K Monitors
• Dual Gold-Mount Plus Battery Bracket (14v/26v) for SmallHD 4K Monitors
• C-stand mount with VESA compatibility
• 4K HDMI to 4K HDMI Cable (120in/305cm)
• 4K HDMI to 4K HDMI Cable (36in/90cm)
• 2-pin to 2-pin Power Cable (18in/45cm)
• 24V Power Supply (Cine 13, 18)
• Ultra QR Articulating Monitor Mount (Baby Pin, C-Stand)
• Premium Monitor Handle for 4K Monitors
• SmallHD 4K Monitor Feet (Set)
• Mounting Rail for Cine 18
• Sun Hood for Cine 18
• Combination Cheese Stick for SmallHD 4K Monitors (3/8 & 1/4-20)
• 1/4-20 Cheese Stick for SmallHD 4K Monitors
• Blank Cheese Stick for SmallHD 4K Monitors
• Rack Mount for Cine 18
• Cine 18 Transport Screen Protector
• CS Desk Mat with Magnetic Strip

Specifications:

Display: 18",  3840 x 2160, 1100nits
Backlight Type: Edgelit LCD
SDI: 4x 12G-SDI in, 4x 12G-SDI out
HDMI: 1x HDMI 2.0 in, 1x HDMI 2.0 out
Power Input: 1x 4-pin XLR

Product SKU:

16-1801

In The Box:

SmallHD Cine 18" 4K High-Bright Production Monitor
SmallHD Transport Screen Protector for Cine 18
Monitor Feet
Monitor Handle
Power Supply
Microfiber Cleaning Cloth
Limited 1-Year Manufacturer Warranty
