5,200W tunable white high intensity point source lamp

The Aputure STORM XT52 is a revolutionary high-output 5,200W tunable white LED point-source fixture designed to redefine professional lighting standards. As the most powerful tunable white LED point-source fixture, the STORM XT52 delivers output greater than a 6,000W HMI. Engineered with Aputure’s revolutionary BLAIR chipset, the XT52 incorporates an advanced diode mix of Blue, Lime, Amber, Indigo, and Red, allowing for exceptional spectral accuracy and refined white-point control.

The STORM XT52 features a fully tunable CCT range from 2,500K to 10,000K, with support for both CIE Daylight and Blackbody white light standards, ensuring unmatched flexibility across any lighting environment. Its advanced white-point control system includes ±G 100% ASC MITC range green-magenta tint correction, allowing seamless integration into mixed-lighting environments. With third-generation Aputure HyperDrive LED driver technology, the XT52 achieves flicker-free performance at all color temperatures above 20% output, ensuring smooth intensity transitions and precision control for high-speed cinematography.

Designed for large-scale productions, the electronic Aputure Mount ensures compatibility with Aputure’s ecosystem of high-output modifiers, including the CF16 Motorized Fresnel and other large-format optical and softbox accessories. Auto output calibration and chip protection optimize light quality when using Aputure Mount modifiers while protecting the LED chip from overheating. Featuring head cables capable of daisy-chaining up to 45 meters, the XT52 provides extended rigging flexibility for studio and location lighting setups.

Engineered to withstand the demands of professional filmmaking, the STORM XT52 boasts an IP65 dust and water-resistant design, ensuring reliability in extreme environments. Its advanced liquid-cooling technology maintains optimal thermal performance, reducing noise and extending LED lifespan. A removable heavy-duty yoke increases storage and rigging possibilities, while its stackable lamp head design is optimized for shelf and head cart storage.

With multiple industry-standard control methods, including Sidus Link, LumenRadio CRMX, Art-Net & sACN via etherCON, and 16-bit DMX512, the STORM XT52 ensures seamless compatibility with modern lighting workflows. Additionally, Sidus NFC Quick Configuration allows for rapid setup and fixture addressing. Its service-friendly modular sub-assembly design incorporates circuit board-level fault inspection and error monitoring, minimizing downtime and maximizing efficiency on set.

The STORM XT52 can be purchased with or without flight cases, allowing users to order the configuration that they need to efficiently store and transport their light. Delivering unparalleled output, precision color accuracy, and next-generation LED technology, the Aputure STORM XT52 redefines the future of high-output LED lighting, offering a powerful, reliable, and intelligent solution for high-end film industry professionals.

BLAIR: The Best Tunable White Light

The Aputure STORM XT52 utilizes the BLAIR (Blue/Lime/Amber/Indigo/Red) light engine, delivering the highest quality white light and greatest +/- green adjustability of any LED technology. The BLAIR light engine's indigo emitters enhance fluorescing materials like natural daylight and tungsten sources.

The STORM XT52's output is also the brightest of any LED point source fixture in the industry, 41,900 Lux at 5M with a 35° reflector. This exceeds the brightness of a 6,000W HMI fixture.

Color Tuning Control

The revolutionary BLAIR light engine can also output saturated colors across more than 70% of Rec.2020 color space using Limited HSIC+ and x,y control modes. Achieve deep crimson sunsets, rich sodium vapor ambers, and subtle color effects without gels.

STORM XT52 is more than twice as powerful as any other point source color light.

Smallest Size and Lowest Weight in Class

The STORM XT52 lamp head weighs 27.80kg (61.29lbs), and can be lifted by one person and operated on a standard crank stand. The portable XT52 control box is the size of a briefcase and weighs just 13.40kg (29.54lbs).

Extend Your Reach

Extend the 7.5M STORM XT52 head cable up to 45M. Place the lamp head in a cherry picker and leave the control box on the ground to save on weight and keep physical controls nearby. Power the STORM XT52 at full brightness on standard 6,500W generators.

Built Rugged and Easy to Service

The STORM XT52 is IP65 weather protected across the entire system, from control box to cables to lamphead and even modifiers.

Ruggedized construction makes the light built for the most challenging environments, and service is easy and fast with the modular internal design.

Runs Full Power Off of Popular Generators

The STORM XT52 is easy to use in any location. The fixture draws 5,200W at full power, meaning it can run on popular 6,500W generators.

If the head cables are extended to 45m, the power draw can rise to 6,000W, and there is a menu control to limit maximum power so that a generator or other power source will not be overtaxed.

High Power Light for High-Speed Photography'

The STORM XT52 offers flicker free output at 20% brightness or more at any recording frame rate. With the high output available from the light and the quality and versatility of the BLAIR light engine, the XT52 is ideal for all high frame rate work, from major action stunts to food product photography.

Features:

• 5,200W Point-Source Tunable White LED with Dynamic CCT & Tint Control
• Highest Power LED Point-Source in the Industry
• Daylight Output Greater than 6,000W HMI
• Ultra-High Color Accuracy: CRI≥96, TLCI≥96, SSI [P3200]: 87, SSI [CIE D5600]: 88, TM-30 Rf (average) 95, TM-30 Rg (average) 100
• Breakthrough LED Chipset: Blue, Lime, Amber, Indigo, Red (BLAIR)
• Advanced Diode Color Mixing Allows Fixture to More Effectively Utilize Each Diode’s Light Output
• Fully Tunable CCT from 2,500K to 10,000K
• Advanced White Point Control with Green/Magenta Color Correction (±G 100% Full ASC MITC Range)
• Flexible White Light Standards (CIE Daylight or Blackbody)
• Aputure HyperDrive LED Precision Driver Ensures Flicker-Free Performance at All Color Temperatures and Hues Above 20% Output
• Electronic Aputure Mount Compatible with Aputure Mount Reflectors, CF16 Motorized Fresnel, and other Large Modifiers and Powered Accessories1
• Auto Output Calibration, Optimization, and Chip Protection Using Aputure Mount Modifiers
• Head Cables Support Daisy Chaining Up To 45m
• IP65 Dust & Water-Resistant
• Advanced Liquid-Cooling Technology
• Supports Sidus NFC Quick Configuration
• Removable Heavy-Duty Yoke for More Rigging and Storage Options
• Multiple Control Methods: Sidus Link App Control, LumenRadio CRMX, Art-net & sACN via etherCON, 16-bit 5-Pin DMX512 In & Out
• Service-Friendly Modular Sub-Assembly Component Design with CircuitBoard-Level Fault Inspection Error Codes and Monitoring
• Stackable Lamp Head Design Optimized for Shelf and Head Cart Storage

Ideal For:

The Aputure STORM XT52 is designed for cinematographers, lighting technicians, rental houses, and studios working in the high-end film, television, and commercial spaces that demand the highest power, color and dimming precision, and durability from their lighting equipment. With unprecedented LED output, dynamic white-light adjustability, and intelligent accessory integration, the XT52 is the ideal alternative to traditional HMIs, enabling productions to achieve cinematic lighting quality with modern LED efficiency and control that outperforms and outlasts HMI technology.

Compatible With:

Optional Accessories (Sold Separately):

• STORM Parallel Beam 70 (AA0706028X)
• STORM XT52 Reflector Kit (AA0706015G)
• Aputure Mount Light Dome 150 (AA0706015H)
• Motorized CF16 Fresnel (AA07060370)
• STORM Parallel Beam 70 Flight Case Kit (AA0706034T)
• Y50X-2011 Male to Female Extendable Head Cable for STORM XT52 (AA0706015K)
• Aputure Mount Lantern 120 (AA0706015J)
• STORM XT52 Skid (AA0706028V)

Dimensions:

Lamp Head with Yoke: 21.7 x 21.3 x 32.7"
Lamp Head without Yoke: 21.7 x 13.9 x 14.3"
Removable Yoke: 21.3 x 27.2"
Control Box: 16.2 x 6.3 x 15.3"
Aputure Mount 35° Reflector: ⌀16.2 x 6.3 x 15.3"

Weight:

Lamp Head with Yoke: 68.56 lbs
Lamp Head without Yoke: 61.29 lbs
Removable Yoke: 7.72 lbs
Control Box: 29.54 lbs
Aputure Mount 35° Reflector: 3.31 lbs

FAQ:

Why is it called STORM XT52?

This light uses the same BLAIR light engine technology found in our earlier STORM 1200x. The STORM lights are Aputure’s latest generation of point source lights, incorporating and expanding upon the earlier Light Storm and Electro Storm lines. All STORM lights use either the BLAIR tunable white or BLAIR-CG tunable color light engines. The alphanumeric convention XT52 connects to our next most powerful light, the Electro Storm XT26. The X is how Aputure refers to bi-color lights, such as the LS 600x Pro, with the letter signifying crossing from one CCT to another. The T refers to tint control, meaning +/- green adjustment. The 52 is in reference to the 5200W power consumption of the light when used with 220v power at full brightness with the standard 7.5M head cable.

Product SKU:

AG07060003

In The Box:

STORM XT52 Lamp Head
STORM XT52 Removable Yoke
STORM XT52 Aputure Mount Protection Cover
STORM XT52 Control Box
Aputure Mount 35° Medium Reflector
AC Power Cable (3.3')
STORM XT52 Head Cable (24.6')
Lightning Clamp
STORM XT52 Lamp Head Flight Case
STORM XT52 Control Box Flight Case
Limited 1-Year Manufacturer Warranty





Note: Power Connectors are sold separately.
